Where standard strip lights leave visible LED dots in direct line of sight or reflecting on glossy surfaces, the cleverly designed diffusion layer of Lumishore’s Lux Superbright Neon Flex Strip Light blends the CRGBW LED light to create a beautiful, homogenous, dot-free experience.
Its bend-flex allows it to adjust around curved surfaces making it ideal for installing under gunwales, cabin headliners or T-tops.
With 180 LEDS per meter and an IP67 Ingress Protection Rating – the SNL180 is suitable for both indoor and outdoor installation on your vessel (above water only).
Full spectrum CRGBW (cold white, red, green, blue, warm white) and white color temperature tuneable (from 2700k to 6500k) in a single neon flex strip.
Control by a momentary switch, or upgrade to full integration with your compatible MFD and/or Lumishore Display.
Neon Flex Strip Lights are dimmable as standard and powered by the Lux Strip Light Driver.
Features
- LUX Collection
- Full Color – Full Color CRGBW
- Warranty
Specifications
| Specification | Value |
|---|---|
| Available colors | Full spectrum CRGBW and white color temperature tuneable in the same strip light |
| of LEDS | 180 Leds per meter |
| Ingress Protection | IP67 |
| Mechanical installation | Screw clips |
| Control options | Momentary switch with option to upgrade to full MFD and optional Lumishore Display |
| Driver | LUX Strip Light Driver |
| of LED strips per driver | Multiple – up to 10m total |
| UV resistant | Yes |
| Salt spray tested | Yes |
Downloads
FAQs
Yes. Always disconnect or isolate the vessel’s power source and battery before installation.
Yes. The guide recommends that a qualified professional carry out both the electrical and mechanical installation.
Yes. Don’t uncoil by picking up one end; uncoil carefully along its length, and don’t let it drop or twist during installation.
Yes. The datasheet lists the electrical installation as “Plug and Play.”
Minimum bend radius is 120mm. Do not bend it in the vertical axis or twist the strip during installation.
The installation guide lists an input range of 23–25V.
After clips are installed, push the strip into the clips; a noticeable “Click” indicates it’s secure.
It installs with the supplied stainless steel clips: screw the clips in place, then push the strip into the clips until you feel a noticeable “Click”.
The guide advises against installing it in areas of strong direct sunlight.
It’s listed for outdoor, partially covered, or indoor locations, for above-water applications only.
It is described as “Fully Encapsulated and Potted with Spot Free Diffuser.”
Contact the SailRACE team — as certified marine experts we’re happy to help with product selection, installation and after-sales servicing, before and after your purchase.
