Victron Energy BAT412123081 12V 230Ah AGM Super Cycle Battery (M8 Terminals)
The Victron BAT412123081 is a high-capacity AGM Super Cycle battery engineered for energy-intensive systems that require deep discharge performance, maintenance-free reliability, and high cycle life. With a 230Ah (C20) rating and sealed construction, it provides robust energy delivery in both mobile and stationary environments. Its M8 terminals ensure secure high-current connections for demanding applications.
Key Features:
- Voltage: 12V
- Capacity: 230Ah (C20 at 10.8V)
- Cold Cranking Amps (CCA): 700A @ 0°F
- Reserve Capacity: 400 minutes @ 80°F
- Terminal Type: M8 bolt
- Technology: AGM Super Cycle (sealed VRLA)
- Dimensions: 532 × 207 × 226 mm
- Weight: 57 kg
- Maintenance: Sealed and zero-maintenance
Exceptional Cycle Performance:
- ≥ 300 cycles @ 100% depth of discharge (DoD)
- ≥ 700 cycles @ 60% DoD
- ≥ 1000 cycles @ 40% DoD
Charging Recommendations:
| Charge Stage | Normal Voltage | Fast Recharge Voltage |
|---|---|---|
| Absorption | 14.2 – 14.6 V | 14.6 – 14.9 V |
| Float | 13.5 – 13.8 V | |
| Storage | 13.2 – 13.5 V |
Recommended Applications:
- Large off-grid solar battery banks
- Heavy-duty backup and UPS systems
- Marine and RV power systems
- Industrial DC equipment and automation
- Hybrid energy storage systems
Technical Notes:
- Recommended charge current: Up to 46A (0.2C)
- Self-discharge: <2% per month at 20°C
- Temperature compensation: –24 mV/°C (entire 12V battery)
- Ideal operating temperature: ~20–25°C for maximum lifespan
Designed for long-term performance in demanding applications, the Victron BAT412123081 is the flagship AGM Super Cycle solution for professionals seeking high capacity, extreme reliability, and extended life in a sealed format.
