Tecma Compass Marine Toilet – ECO Panel
The Tecma Compass Marine Toilet is a compact and modern sanitation solution developed in collaboration with Tony Castro Yacht Design. Its smart footprint and cutaway back allow flexible installation against flat or angled walls, maximizing available space on board. The Compass is available in two versions – standard and short – ensuring the perfect fit for a wide range of vessels.
Key Features:
- Compact and space-saving design
- Available in two versions: Standard (21.5 kg) and Short (19.5 kg)
- Flexible installation: suitable for flat or oblique walls, even close to the hull
- MAC 4 12/24V outlet pump with high reliability
- Solenoid water inlet (optional inlet pump)
- ECO rocker switch as standard control (other panels optional)
- Quiet operation with low water and energy consumption
- Thermosetting seat with soft-closing mechanism
Technical Specifications:
| Model | Weight | Water Usage | Seat & Cover | Outlet Pump | Inlet Device | Control Panel |
|---|---|---|---|---|---|---|
| Compass (Standard) | 21.5 kg (47.3 lbs) | 0.5 – 2.0 L (0.1 – 0.5 gal) | Thermosetting with soft-closing | MAC 4, 12/24V | Solenoid / Optional inlet pump | ECO rocker switch (other options available) |
| Compass Short | 19.5 kg (40.0 lbs) | 0.5 – 2.7 L (0.1 – 0.7 gal) | Thermosetting with soft-closing | MAC 4, 12/24V | Solenoid / Optional inlet pump | ECO rocker switch (other options available) |
The Tecma Compass toilet range combines style, functionality, and eco-efficiency, ensuring comfort and reliability on board. Chosen by prestigious yacht builders such as Absolute, Cranchi, Galeon, Oryx, Silvercraft, and Dominator, the Compass is a trusted marine sanitation solution for vessels worldwide.
