Talamex Medium Galvanized Single-Speed Hand Trailer Winch – 545–815 kg
The Talamex Medium Series Hand Winch is a galvanized manual winch engineered for demanding pulling and recovery applications. Featuring a single-speed gearbox, a neutral position, and a bi-directional ratchet mechanism, it provides controlled operation while winding in either direction. The galvanized steel construction offers excellent protection against corrosion, making the winch suitable for marine and outdoor environments.
The range includes models designed for either webbing strap and hook or 5 mm steel wire rope, with pulling capacities from 545 kg to 815 kg. An optional gear wheel protective cover is available separately.
Key Features
- Single-speed manual hand winch.
- Galvanized steel construction.
- Neutral gear position.
- Ratchet mechanism operating in both directions.
- Available for webbing strap or 5 mm steel wire rope.
- Optional gear wheel protective cover available.
Available Variants
| Talamex Part No. | Model | Gear Ratio | Pulling Capacity | Drum Capacity |
|---|---|---|---|---|
| 76.708.000 | WT-73-12 | 4:1 | 545 kg | 6 m webbing strap with hook |
| 76.709.000 | WT-73-14 | 4:1 | 636 kg | 15 m × 5 mm wire rope |
| 76.716.000 | WT-73-18 | 5:1 | 815 kg | 20 m × 5 mm wire rope |
Mounting Dimensions
| Dimension | Value |
|---|---|
| A | 16 mm |
| B | 32 mm |
| C | 36 mm |
| D | 65 mm |
| E | 10 mm |
Technical Specifications
| Specification | Details |
|---|---|
| Product Type | Manual Hand Trailer Winch |
| Series | Medium |
| Drive | Single-Speed |
| Finish | Galvanized |
| Ratchet | Bi-Directional |
| Neutral Position | Yes |
| Rope Compatibility | 5 mm steel wire rope or webbing strap (depending on model) |
| Available Pulling Capacities | 545 kg, 636 kg, 815 kg |
