Mastervolt 68000420 – MVSV Gel Battery 2V 420Ah – Deep-Cycle, Long Life, Industrial-Grade
The Mastervolt MVSV 2V 420Ah Gel Battery (Part No. 68000420) is engineered for applications requiring high reliability and longevity under intensive cyclic load. With a 420Ah capacity (C10) and over 1000 full charge/discharge cycles, this 2V battery is ideal for large systems assembled in 12V or 24V configurations. Thanks to sealed gel technology, it is maintenance-free and safe to install in any orientation. Its rugged construction and long lifespan make it a preferred choice for industrial and marine systems.
Key Features:
- High-capacity deep-cycle gel battery – 420Ah at C10 rate
- Over 1000 full cycles – excellent for intensive use
- Series connection compatible for 12V or 24V banks
- Maintenance-free sealed design – no gas emissions
- Fast charge support – up to 210A
- Installs vertically or horizontally for system flexibility
- Includes required interconnect cables (length selectable)
- Robust casing for long service life in demanding environments
- Backed by a 7-year pro-rata warranty
Typical Applications:
- Large-scale off-grid and backup power systems
- Marine propulsion and auxiliary power storage
- Industrial and telecommunications energy infrastructure
- Renewable energy installations with deep cycle demands
Technical Specifications:
| Specification | Value |
|---|---|
| Nominal Voltage | 2 V |
| Nominal Capacity (C10) | 420 Ah |
| Maximum Charge Current | 210 A |
| Terminal Type | F-M8 |
| Installation Orientation | Vertical or horizontal |
| Dimensions (L × W × H) | 126 x 208 x 515 mm / 5.0 x 8.2 x 20.3 in |
| Weight | 30 kg / 66.1 lb |
