Key details
- Part No.: 1647
- Series: Spinnaker Pole Cars
Overview
Harken® spinnaker pole cars feature recirculating ball bearings to permit adjustment under any load. They roll freely on low-beam traveler track to allow crew to adjust for optimal sail shape. Midrange and Big Boat cars accept two popular toggle studs and Harken bell end fittings.
Specifications
| Specification | Value |
|---|---|
| A (in) | 1 3/16 in |
| A (mm) | 30 mm |
| B (in) | 2 1/8 in |
| B (mm) | 54 mm |
| Length (in) | 5 3/16 in |
| Length (mm) | 132 mm |
| Maximum spinnaker area (ft²) | 1500 ft² |
| Maximum spinnaker area (m²) | 140 m² |
| Maximum working load (kg) | 1043 kg |
| Maximum working load (lb) | 2300 lb |
| Pin Ø (in) | 5/8 in |
| Pin Ø (mm) | 16 mm |
| Pole end | Sparcraft toggle |
| Use with track/rail | R27 |
| Weight (g) | 680 g |
| Weight (oz) | 24 oz |
| Width (in) | 2 3/4 in |
| Width (mm) | 70 mm |
