Harken 27 mm ESP Adjustable CB Car — Sheave, 2-to-1

CB adjustable genoa lead cars feature recirculating Torlon® ball bearings for easy adjustment under full sheet loads. Stainless steel sheave carriers pivot 60 degrees to accommodate changing lead angles. Torlon is a registered trademark of Solvay Advanced Polymers L.L.C.

Product Specifications

Sheave Ø (mm) 57 mm
Sheave Ø (in) 2 1/4 in
Length (mm) 132 mm
Length (in) 5 3/16 in
Width (mm) 70 mm
Width (in) 2 3/4 in
Weight (g) 659 g
Weight (oz) 23.25 oz
Maximum working load (kg) 1043 kg
Maximum working load (lb) 2300 lb
Breaking load (kg) 2268 kg
Breaking load (lb) 5000 lb
Use with track/rail R27
