Garmin GND 10 Black Box Converter

Original price was: $126.40.Current price is: $66.58.

Sale!
SKU: 010-01226-00 Category:
Share
  • Convert data between the Nexus network and NMEA 2000®
  • Provides compatibility between Nexus and Garmin products
  • Simple plug-and-play installation between Nexus, NMEA 2000 and USB
  • It is not necessary to configure the user or the system
  • GND 10 allows computer applications such as NexusRace™, Expedition, Adrena or SeaTrack to communicate between Nexus and NMEA 2000 networks

The GND 10 black box converter seamlessly integrates Nexus instruments and sensors with Garmin’s range of devices. Convert data between the Nexus network and NMEA 2000 to provide compatibility between Nexus and Garmin products, including gWind™, gWind™ Wireless and gWind™ Race transducers. Simple plug-and-play installation between the Nexus and NMEA 2000 networks, with USB connectivity, which eliminates the need to configure the system and the user.

GND 10 allows computer applications, such as NexusRace, Expedition, Adrena or SeaTrack to communicate between the Nexus and NMEA 2000 networks. It also allows GND 10 software updates on the NMEA 2000 network. The current NexusRace PC application can be used to update software, configure and calibrate Nexus devices over USB through the FDX protocol.

Specifications:

Misc
  • Dimensions of the unit: A. X a. X p.: 170 X 90 X 50 mm
  • Weight: 196 g
  • Water resistance: Yes (IPX7)
  • Temperature range: From -15 °C to 70 °C (from 5 °F to 158 °F)
  • Voltage range: 9-16 V
  • Power consumption: 0.52 W
  • Safety distance from the compass: 0.1 m
  • Precision angle: N/A
  • Speed: N/A
  • Load equivalence number (LEN) NMEA 2000®: 4
  • Wireless connectivity: no
From Nexus to NMEA 2000 From NMEA 2000 to Nexus
Apparent wind angle ✔ ✔
Apparent wind speed ✔ ✔
Speed of the boat in the water ✔ ✔
Journey on land ✔
Journey to waypoint ✔
Cross track error ✔
Depth ✔ ✔
Distance to the waypoint ✔
Latitude ✔
Length ✔
Magnetic Direction ✔ ✔
Magnetic variation ✔
Speed on the ground ✔
Rumbo real ✔ ✔
Angle of the real wind ✔ ✔*
Real wind speed ✔ ✔*
UTC date ✔
UTC time ✔
Water temperature ✔ ✔
Barometric pressure ✔

FAQs

What should I check before drilling into my boat for installation?

Always check the opposite side of the mounting surface before drilling to avoid damaging the vessel.

What should I do before drilling for installation?

Always check what is on the opposite side of the mounting surface before drilling to avoid damaging the vessel.

How is the GND 10 mounted to the boat?

Use the included screws to mount the device on your boat. If not appropriate for your surface, use suitable hardware separately.

How do I connect the GND 10 to a Nexus network?

You must connect a Nexus network device to one of the NEXUS ports on the GND 10.

Can I use third-party sailing software with GND 10?

When connected to a computer, you can use data from the device with programs such as Expedition and Adrena.

How do I calibrate advanced wind transducers?

When connected to a computer, you can calibrate advanced wind transducers using the NexusRace software via the GND 10 USB connection.

How do I know if the device is operating correctly when connected to a computer?

When the GND 10 is connected via USB, the LED near the USB port flashes green if it is operating properly.

What should I do if the LED flashes red?

A flashing red LED indicates an error; for assistance, go to support.garmin.com.

Who do I contact for help with installation, servicing or advice?

Contact the SailRACE team — as certified marine experts we’re happy to help with product selection, installation and after-sales servicing, before and after your purchase.
