Garmin Double-Beam Stern-Mount Transducer — 4-Pin

Original price was: $52.80.Current price is: $32.55.

Sale!
SKU: 010-10249-20 Category:
Share

This dual-beam transducer replaces the transducer included with the echo™ series probe.

A 500 W transducer with 4 pins, has a maximum depth of 900 ft (274 m); an operating frequency of 77 to 200 kHz; a beam of 45 to 15 degrees and is mounted at an aft mirror angle of between 0 and 70 degrees.

The transducer kit is supplied with the installation instructions. Follow the instructions carefully to avoid damage to the boat.

Specifications:

Physical And Performance Characteristics
Frequency 77/200 Khz
Energy 500 W
Beam Width 45°/15°
Maximum Depth 1,900 ft.
Cable Length 30 ft.
DEPTH/SPEED/TEMPERATURE Depth and Temperature
Number of Sideburns 4-pin
Aft Mirror Angles Allowed 0°-70° degree transom

FAQs

Are there best practice installation instructions included?

Installation instructions are supplied with the transducer kit; follow them carefully to avoid boat damage.

What should be done if difficulty is experienced during installation?

If difficulties occur during installation, you should contact Garmin Product Support or seek the advice of a professional installer.

Is this transducer suitable for boats with inboard engines?

Transom-mount transducers will not work on vessels with an inboard engine.

Will the transducer work on a stepped hull?

Transom mount transducers will not work on stepped hulls.

Who do I contact for help with installation, servicing or advice?

Contact the SailRACE team — as certified marine experts we’re happy to help with product selection, installation and after-sales servicing, before and after your purchase.
