Faria Spun Silver 2″ Oil Pressure Gauge [16002]

Spun Silver 2″ Oil Pressure Gauge (80 PSI)

Perimeter-lighted Silver dial with bold Black graphics, polished stainless steel bezel, contoured Black pointer, and domed glass lens.

A pressure gauge operates by sending a low amperage current through the gauge’s meter to ground via a sending unit with variable resistance. The resistance of the sending units increase or decrease with the changes in pressure, temperature, etc…

As the sender’s resistance varies, the amount of current allowed to flow through it to ground changes and the meter deflects, showing the change in pressure.

2″- Hole Size: 2.0625″ (53mm)

Specifications:

• Domed, Scratch Resistant Lens
• Stainless Steel Bezel
• LED Illuminating around the Perimeter of the Dial
• Dual Scale – Imperial and Metric

Factory P/N GP9623

*Sold as an Individual

**Gauge Cover not Included

Specifications:

• Gauge Type: Oil Pressure
• Voltage – Input Range (Volts): 12/24 V
• Gauge Size: 2″
• Box Set: No
• Series: Spun Silver
• Box Dimensions: 4″H x 4″W x 5″L WT: 0.3 lbs
• UPC: 759266160026
