Chain Tackle 500kg
Compact and efficient manual hoisting tackle, also known as quick tackle. Built for professional use in shipyards and heavy industry.
- Lightweight sheet steel housing with modest height
- Modern design, simple to operate
- Tested at 50% static overloading
- Upper and lower swivel hooks equipped with safety clips
- High-grade governed load chain, DIN 5684 compliant
- Optional chrome galvanized chain available
- Customizable hoisting heights, suitable for outdoor use
- High safety factor: 4:1
- Meets Health and Safety Inspectorate requirements
- Type: STM
- Standard hoisting height: 3 m
- Operating height: 2.5 m
- Load chain: DIN 5684 – grade 80
- Product code: 09.68.005
- Number of parts: 1
- Jaw width: 37 mm
- Building height: 285 mm
- Weight: 9.0 kg
- Manual power: 25 kg
- Hoisting capacity: 500 kg
