Blue Sea 1217 12V DC 12 Position w/Digital Meter

12 Volt DC 12 Position w/Digital Meter

Features:

• 4 to 32 branch circuits with installed 15 Ampere circuit breakers
• Available with voltmeters, ammeters, and digital multimeters
• Includes 4205-Square Format Label Set

Specifications:

• Positions:12
• Nominal Voltage:12V DC
• Maximum Amperage*:100A per bus
• Height:7.75″ (196.85mm)
• Width:9.25″ (234.95mm)
• Depth:4.00″ (101.6mm)
• Weight:5.99lb (2.72kg)

* Maximum amperage ratings are dependent on use of appropriately sized fuses and wire for a given application.

Includes:
(12) – 7403 – A-Series Flat Rocker Circuit Breaker – Single Pole 15A
(1) – 4205 – Basic DC Label Kit – 30 Black Square Labels [LABEL]
(1) – 8248 – DC Digital Multi-Function Meter with Alarm (Meter)

WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Specifications:

• AC/DC: DC
• Box Dimensions: 6″H x 10″W x 13″L WT: 5.8 lbs
• UPC: 632085012175

Quick Guide (pdf)
Owner’s Manual (pdf)

SKU:BLU-1217
